This layer performs convolution in two dimensions with a factorization of the convolution kernel into two smaller kernels. Corresponds to the Keras Separable Convolution 2D Layer.

- Name prefix
- The name prefix of the layer. The prefix is complemented by an index suffix to obtain a unique layer name. If this option is unchecked, the name prefix is derived from the layer type.
- Filters
- The dimensionality of the output space (i.e. the number of output filters in the convolution).
- Kernel size
- A tuple of 2 integers, specifying the height and width of the 2D convolution window.
- Strides
- A tuple of 2 integers, specifying the strides of the convolution along the height and width. Specifying any stride value != 1 is incompatible with specifying any dilation_rate value != 1.
- Padding
- Different padding modes to apply to the spatial dimensions
(excluding the batch and channel dimensions)
of the inputs before the
pooling operation. The padding will be done
with zeroes. A detailed
explanation of the different modes can be
found
here
.
- Valid: No padding
- Same: Padding such that the spatial output dimension do not change.
- Full: Padding with kernel size - 1

- Dilation rate
- A tuple/list of 2 integers, specifying the dilation rate to use for dilated convolution. Currently, specifying any dilation_rate value != 1 is incompatible with specifying any stride value != 1.
- Depth multiplier
- The number of depthwise convolution output channels for each input channel.
- Activation function
- The activation function to use.
- Use bias?
- If checked, a bias vector will be used.
- Depthwise initializer
- Initializer for the depthwise kernel matrix.
- Pointwise initializer
- Initializer for the pointwise kernel matrix.
- Bias initializer
- Initializer for the bias vector.
- Depthwise regularizer
- Regularizer function applied to the depthwise kernel matrix.
- Pointwise regularizer
- Regularizer function applied to the pointwise kernel matrix.
- Bias regularizer
- Regularizer function applied to the bias vector.
- Activation regularizer
- Regularizer function applied to the output of the layer (its "activation").
- Depthwise constraint
- Constraint function applied to the depthwise kernel matrix.
- Pointwise constraint
- Constraint function applied to the pointwise kernel matrix.
- Bias constraint
- Constraint function applied to the bias vector.

- This node has no views

- No workflows found

You want to see the source code for this node? Click the following button and we’ll use our super-powers to find it for you.

To use this node in KNIME, install the extension KNIME Deep Learning - Keras Integration from the below update site following our NodePit Product and Node Installation Guide:

v4.4

A zipped version of the software site can be downloaded here.
